120M 4K HDMI EXTENDER
HF-HKEL120
Product Features
- Support the highest video resolution 1080p/60Hz
- 120M long distance transmission
- Both the TX and RX support 3.5MM left and right audio output
- Low power consumption, low temperature and high safety
- Support IR remote control ≥ Support USB mouse and keyboard extension
Specifications
- General Specifications
- PHYSICAL INTERFACE TX
- RX
General Specifications
Length of CAT-5E/6 cable between RX and TX
Up to 120 meters
HDMI Input
1080p/1080i/720p/576p/576i/480p/480i
HDMI Output
1080p/1080i/720p/576p/576i/480p/480i
Max Bandwidth
150MHZ
Max Baud Rate
4.5Gbps
Input Video Signal
0.5-1.5Volts p-p
Output DDC Signal
5Volts p-p (TTL)
Input HDMI Cable Distance
≤10m AWG26 HDMI standard cable
Output HDMI Cable Distance
≤15m AWG26 HDMI standard cable
TX Max Working Current
300mA
RX Max Working Current
300mA
Power Adapter Format
Input:AC (50HZ,60HZ)100V-240V; Output: DC5V/1A
Operating Temperature Range
(-15 to +45C)
Operating Humidity Range
5 to 90%RH (No Condensation)
Dimension (LxWxH)
94x84x24(mm)
TX Weight
220g
RX Weight
220g
PHYSICAL INTERFACE TX
Port
Function description
Input
HDMI Input Port
DC/5V
5V DC Power input port
Cat5E/6
Cat5e/6 cable output port
USB
USB-PC
Audio
Stereo output
IR-TX
3.5MM IR transmitter
EDID
1080P and 720P switch button (press for 3 seconds)
RX
Port
Function description
Output
HDMI Output Port
DC/5V
5V DC Power input port
Cat5E/6 cable
Cat5e/6 cable input port
IR-RX
3.5MM IR receiver
USB 1
USB for mouse or keyboard
USB 2
USB for mouse or keyboard
Audio
Stereo output
