CAT-6 Outdoor Cable 305 MTRS
HFC-OC624AW-305
Product Features
Specifications
- General Specifications
- COLOR CODE
- PHYSICAL CHARACTERISTICS
- ELECTRICAL PARAMETER
General Specifications
Conductor
Solid Bare Electrolytic Grade Copper
Nominal Conductor Diameter
24 AWG (0.557 ± 0.020 mm)
Insulation
Polyethylene (HDPE)
Pairing
Twisted Into Two Core
No.of Pair
4, Each Pair Twisted
COLOR CODE
Pair #1
Orange-White with Orange
Pair #2
Brown-White with Brown
Pair #3
Blue-White with Blue
Pair #4
Green-White with Green
Inner Shealth
PVC (L-Grey)
Armoring
Alloy
Colour Of Sheath
Black
Outer Shealth materia
PVC
Approximate OD
9.0 ± 0.30 mm
Rip Cord
Yes
Sequential Marking
At Every Meter
Cross Filler
HDPE
Temperature Rating
-20 to + 60 c
Packing
305 Mtrs in a Box
PHYSICAL CHARACTERISTICS
Installation Temperature
0 to + 50 c
Storage Temperature
-20 to + 75 c
Operating Temperature
-20 to + 60 c
ELECTRICAL PARAMETER
Conductor Resistance (DC)
93.5Ω /1000 mtr @20 c Max
Resistance Unbalance
5% Max
Mutual Capacitance
5.6 nf/100 mtr Max
NVP
69%
Impedance
100 +- 15% Ω
Worst Cable Skew
45 ns/100 mtr
