4MP 4G BULLET CAMERA
HIPC-T4114-DLSG-R1
Product Features
- 4 MP High Definition – 4MP, 2560×1440 video @ 15FPS
- Lens – 4mm / 6mm Fixed Lens
- Video Compression – H.265 / H.264
- Low-Light Performance – 0.01Lux (F1.6, AGC ON), 0Lux with IR
- Night Vision – Upto 40m IR Range, 20m White Light
- Storage Support – MicroSD Card up to 512GB
- Connectivity – RJ45 Ethernet, 4G LTE SIM Support
- Cybersecurity – AES 256-bit Encryption, HTTPS & Trusted Boot
- Power Supply – DC12V ±15%, Max. 6.5W
- Protection Rating – IP67 Weatherproof Rating
Specifications
- CAMERA ORE FEATURES
- VIDEO
- SECURITY
- INTERFACE
- NETWORK
- GENERAL
CAMERA ORE FEATURES
Image Sensor
1/3" CMOS Image Sensor
Minimum illumination
Color:0.01Lux@(F1.6,AGC ON), B/W:0Lux with IR
Shutter Speed
1s-1/100000s
Day&Night
IR-cut filter with auto switch (ICR)
Smart IR
upto 40m
Wave length
850nm
White Light Distance
20m
WDR
DWDR
Focal Length
4mm/6mm
Aperture Range
F1.6
Aperture Type
Fixed
Field of View
75.3°(H), 39.9°(V), 87.1°(D)
Digital Zoom
16x
DORI Distance
DORI Distance Detect:59.26m Observe:23.52m Recognize:11.85m Identify:5.93m
VIDEO
Video Compression
H.265,H.264
Video Bit Rate
128~6144 Kbps
Audio Compression
G.711U
Max. Resolution
4MP, 2560x 1440
Main Stream
15fps(2560 x 1440, 2304 x 1296, 1920×1080, 1280×720)
Sub Stream
15fps(704× 576, 352× 288)
AGC
Supported
3DNR
Supported
ROI
Supported
OSD
4 areas
Privacy Mask
4 areas
SECURITY
Cyber Security
AES 256-bit Encryption, Configuration encryption, trusted execution, Digest, security logs, account lockout, syslog, video encryption, HTTPS, trusted upgrade, trusted boot
INTERFACE
Network Interface
1×RJ-45(10/100Base-T)
Audio
1 × input,and 1 × output
Built-in Mic And Speaker
Supported
Alarm
1 × input, and 1 × output
Reset Button
Supported
Micro SD Card
Support upto 512GB
LTE (4G Sim)
LTE-FDD B1/3/5/8 and LTE-TDD B34/38/39/40/41
Network Speed
10 Mbps downlink / 5 Mbps uplink
Sim Card
Airtel, Jio, BSNL and Vodafone Idea
NETWORK
Protocols
TCP, UDP, HTTP, HTTPS, DNS, RTSP, RTMP, DDNS, SMTP, FTP, NTP, DHCP, IGMP, ICMP, RTSPS,
Hearbeat
Supported
User/Host
8 users
Web
IE10+, Firefox52+, Edge89+, Safari11+, Chrome57+
GENERAL
Operating Temperature
-35℃~65℃(-31℉~149℉)
Operating Humidity
≤95%RH
Storage Temperature
-35℃~65℃(-31℉~149℉)
Storage Humidity
10%~95%RH(non-condensing)
Power Supply
DC12V±25%, Max. 7W, PoE:IEEE 802.3af, Max. 8W
Certification
EMI/EMC, ISO9001, CE, FCC and RoHS, BIS, STQC approved compliance report, REACH, ESD 4KV, BIS-ER-01, BIS-IS-13252
Ingress Protection
Surge4000V, ESD6000V, IP67, IK10
Package Dimensions
250(L)180(W)175(H)mm
Gross Weight
0.3kg
NetWeight
0.25kg
