4MP IP BULLET CAMERA
HC-IPC-TQA4314L-DLK-0400
Product Features
- High quality image with 2MP, 1/2.9"CMOS sensor
- 2MP (1920x1080) @30/25fps; 720P (1280x720) @30/25fps
- Smart H.265, H.265, H.264
- Built-in Mic
- Warm Light, up to 30m (98ft) warm light distance
- 2D/3D DNR (Digital Noise Reduction)
- Support 128GB Micro SD card
- Support PoE power supply
- 3-Axis
- IP67 Ingress Protection
Specifications
- CAMERA
- VIDEO
- SMART
- AUDIO
- STORAGE
- NETWORK
- INTERFACE
- GENERAL
CAMERA
Sensor
1/2.9", 4.0 megapixel, progressive scan, CMOS
Min. Illumination
Colour: 0.005 lux (F1.6, AGC ON)
Shutter
Auto/Manual, 1 ~ 1/100000s
Adjustment Angle
Pan: 0° ~ 360°, Tilt: 0° ~ 90°, Rotate: 0° ~ 360°
Lens
4.0mm@F1.6
Iris
Fixed
Angle of view(H)
83.7°
Warm Light Range
Up to 30m (98ft)
Angle of view(H)
83.7°
Light On/Off Control
Auto/Manual
Noise Reduction
2D/3D DNR
S/N
>52dB
WDR
DWDR
AWB (Auto white balance)
Auto/Outdoor/Fine Tune/Sodium Lamp/Locked/Auto2
Defog
Digital Defog
VIDEO
Video Compression
Smart H.265, H.265, H.264
H.264 code profile
Baseline profile, Main profile, High profile
Frame Rate
Main Stream: 2MP (1920x1080), Max 30fps; 720P (1280x720), Max 30fps Sub Stream: D1 (720x576), Max 30fps; 640x360, Max 30fps; 2CIF (704x288), Max 30fps; CIF (352x288), Max 30fps
Video Bit Rate
128 Kbps~6144 kbps
Video stream
Dual streams
HLC
Supported
BLC
Supported
Smart Illumination
Supported
OSD
Up to 4 OSDs
ROI
Up to 8 areas
Privacy Mask
Up to 4 areas
SMART
Intelligent Analysis
Basic Detection: Motion Detection, Audio Detection
General Function
Watermark, IP Address Filtering, Access Policy, ARP Protection, RTSP Authentication, User Authentication, HTTP authentication
AUDIO
Audio Compression
G.711U, G.711A
Audio Bitrate
64 Kbps
Suppression
Supported
Sampling Rate
8KHz
STORAGE
Edge Storage
Micro SD, up to 128 GB
NETWORK
Protocols
IPv4, IGMP, ICMP, ARP, TCP, UDP, DHCP, RTP, RTSP, RTCP, RTMP, DNS, DDNS, NTP, UPnP, HTTP, HTTPS, Qos, SSL/TLS
Compatible Integration
ONVIF (Profile S, Profile T, Profile G), API, SDK
INTERFACE
Network
1 RJ45 10M/100M Base-TX Ethernet
Built-in Mic
Supported
GENERAL
Power
12 V DC±25%, PoE (IEEE802.3 af) Power consumption: Max 7.8W
Dimensions (L x W x H)
162 × 67 × 67mm (6.4” × 2.6” × 2.6”)
Working Environment
-30°C ~ 60°C (-22°F ~ 140°F), Humidity: ≤95% RH (non-condensing)
Weight
0.24kg (0.53lb)
Material
Metal + plastic
Surge protection
4KV
Ingress Protection
IP67
