4MP IP BULLET CAMERA
HC-lPC-TQA4314L-TWL-0400
Product Features
- Sharp & Clear Video: Captures high-quality 4MP resolution for detailed and crisp images.
- Smooth Playback: Records at 30/25 frames per second for fluid, lag-free video.
- Smart Video Compression: Supports Smart 265, H.265, H.264, and MJPEG to save storage without losing quality.
- Full-Color Night Vision: Dark Hunter technology delivers bright, full-color images even in complete darkness.
- Enhanced Clarity in Any Light: 120dB WDR ensures a clear view even in bright or shadowy areas.
- Optimized for Narrow Spaces: 9:16 Corridor Mode is perfect for hallways and alleyways.
- Built-in Microphone: Captures clear audio to enhance security monitoring.
- Bright White LED Light: Provides up to 30 meters of illumination for better visibility at night.
- Large Storage Capacity: Supports up to 512GB Micro SD card for recording without extra devices.
- Weatherproof & Durable: IP67-rated, meaning it’s waterproof and dustproof for outdoor use.
- Easy Installation & Power: PoE support allows both power and data through a single cable for a simple setup.
- Adjustable Viewing Angle: The 3-axis design makes it easy to position for the perfect coverage.
Specifications
- CAMERA
- Lens
- ILLUMINATOR
- VEDIO
- IMAGE
- Events
- AUDIO
- STORAGE
- NETWORK
- INTERFACE
- GENERAL
CAMERA
Sensor
1/2.7", 4.0 megapixel, progressive scan, CMOS
Min. Illumination
Colour:0.0003lux (Fl.0, AGC ON)
WDR
120db
S/N
>52Db
Adjustment angle
Pan: 360°,Tilt:0°,Rotate: 0°- 360°
Lens
Lens
2.8mm@Fl.O, 4.0mm@F1.O
Iris
Fixed
Field of View (H)
99.0° N77.5°
Field of View (V)
53.0° N42.5°
Field of View (D)
118.0° 91.50°
ILLUMINATOR
Warm Light Range
up to 30m (98ft)
Light On/Off Control
Auto/Manual
VEDIO
Video Compression
Smart 265, H.26S, H.264, MPEG
Frame Rate
Main stream: 1080P (1920* 1080), Max 30fps; 720P (1280•720), Max 30fps; Sub Stream: 720P (1280*720), Max 30fps; Dl (720*576), Max 30fps; 30fps; Max 30fps; Max 30fps;
H.264 code profile
Baseline profile, Main profile, High profile
Video Bit Rate
1 'R Kbps%144Kbps
U-code
Support
ROI
Up to 8 areas
Video stream
Dual streams
OSD
Up to 4 OSDs
Privacy Mask
Up to 4 areas per scene
White Balance
Auto/Outdoor/Fine Tune/Sodium Lamp/Locked/Aut02
Digital noise reduction
2D/3D DNR
Smart IR
Support
Flip
Normal/ Vertical/ Horizontal/180'/WClockwise/900 Anti-clockwise
HLC
Support
BLC
Support
Defog
Digital Defog
Events
Basic Detection
Line Crossing, intrusion(based on human body detection), Motion detection, Smart motion detection, Tampering alarm, Audio Detection
General Function
Watermark, IP Address Filtering, Access Policy, ARP Protection, RTSP Authentication, User Authentication, HTTP authentication
AUDIO
Audio Compression
G.711U, G.711A
Audio Bitrate
64 Kbps
Suppression
Support
Sampling Rate
8KHz
STORAGE
Edge Storage
Micro SD, up to 512GB
Network Storage
ANR,NAS(NFS)
NETWORK
Protocols
IPv4, IPv6, IGMP, ICMP, ARP, TCP, UDP, DHCP, PPPoE, RTP, RTSP, RTCP, DNS, DDNS, NTP, FTP, UPnP, HTTP, HTTPS, SMTP, 802.1x, SNMP, Qos, RTMP,SSL/TLS
Compatible Integration
ONVIF (Profile S, Profile G, Profile T), API, SDK
User/Host
Up to 32 users. 2 user levels: administrator and common user
Security
Password protection, Strong password, HTTPS encryption, Export operation logs, Basic and digest authentication for RTSP, Digest authentication for HTTP, TLS 1.2, WSSE and digest authentication for ONVIF
Web Browser
Plug-in required live view: IE 10 and above, Chrome 45 and above, Firefox 52 and Edge 79 and above, Plug-in free live view: Chrome 57.0 and above, Firefox 58.0 and above, Edge 16 and above
INTERFACE
Built-in Mic
Support
Network
1 * RJ45 IOM/IOOM Base-TX Ethernet
GENERAL
Power
DC PoE (IEEE 802.3af)
Power consumption
Max 2.8W
Power Interface
Ø 5.5mm coaxial power plug
Dimensions (L x W x H)
206 x 73 x 73mm (8.1" x 2.9" x 2.9")
Weight
0.47kg(1.041b)
Material
Graphene + Metal
Working Environment
-30t 60t (-22'F 140'F), Humidity: RH (non-condensing)
Storage Environment
-30'C 60'C (-2?F 1400 F), Humidity: s95% RH (non-condensing)
Surge protection
4KV
Reset Button
Support
