5 PORT NETWORK SWITCH
EST105
Product Features
- 5-port 10/100Mbps Ethernet Switch is a desktop switch, which is specially designed for families, offices, dormitories etc.,
- Up to 200Mbps full duplex rate brings blazing fast Internet access. Plug-and-play
- design makes installation easy
- Low power consumption makes you enjoy a healthy e-life. Compatible with computers, printers, smart TVs, NAS, smart game consoles, IP-cameras
- Play the device as long as you plug it, without any configuration Rapid store and forward mechanism guarantees you a fluent and rapid online gaming, HD video and IP camera monitoring experience
- Supports wall or desktop mounting. The wall-mounting guarantees a stable and firm network cabling when you deploy a network outdoor/indoor, like IP camera monitoring.
- Lower consumption. The max power consumption is 1.6W. It is low carbon and energy-sav
Specifications
- Specifications:
Specifications:
Standards
IEEE 802.3, IEEE 802.3u, IEEE 802.3x
Interface
5x10/100M auto-negotiation RJ45 ports (Auto MD
Transmission Media
10Base-T: Cat. 3 UTP or better 100Base-TX
Forwarding Speed
880pps 100Mbps: 148800pps
Power Supply
Input: AC:100-240V; 50/60Hz Output: 5.0V 0.6A (External Power Adapter)
Lightning Level
6kV in Common Mode Protection for all ports 6kV in Common Mode, 4kV in Differential Mode Protection for
Product Dimensions (L x W x H)
82.00mmx52.00mmx22.30mm
LEDs
1x Power, 5x Link/Act
Switching Capacity
1.0Gbps
MAC Address Table
1K
Power Consumption
Maximum: 1.60W (220V)
Transfer Method
Store and Forward
Access Control
CDMA/CD
MAC Address Learning
Automatic update
Temperature
Operating Temperature: 0℃~40℃ Storage Temperature: -40℃~70℃
Humidity
Operating Humidity: 10%~90% non-condensing Storage Humidity
Compatible OS
Windows 8 32/64 bit, Windows 7 32/64 bit, Windows xp 32/64 Bit, Linux, MAC OS
Power Adapter
(5V0.6A)
