6 Port PoE Switch
HF-S04E2-65WH
Product Features
- 4*10/100Mbps PoE RJ45 ports (port1~port4)
- 2*10/100Mbps RJ45 ports (port5~port6)
- Maximum power of power supply: 65W
- Provide two 10/100M RJ45 uplink simultaneously
- All ports support 6KV lightning protection
Specifications
- PRODUCT SPECIFICATIONS
PRODUCT SPECIFICATIONS
Networking Ports
4*10/100Mbps PoE RJ45 ports (port1~port4) 2*10/100Mbps RJ45 ports (port5~port6)
Network Standard
IEEE 802.3i, IEEE 802.3u, IEEE 802.3x, IEEE 802.3af, IEEE 802.3at, IEEE 802.3bt
Performance
Bandwidth: 1.2Gbps Packets Forwarding Rate: 0.89Mpps MAC table size: 1K Forwarding type: Storage and Forwarding
LED
Power Indicator LINK/ACT Indicator PoE Indicator
PoE
1/2(+), 3/6(-)
POWER
Port 4 max power: 60W PoE budget: 65W
Dimension
WxDxH: 190mmx131mmx40mm
Evironment
Working Temperature: 0 ° ~ 40 °C Storage Temperature: -40℃~70℃ Working Humidity: 10% ~ 90% RH nun-condensing Storage Humidity: 5% ~ 90% RH nun- condensing
