8 PORT GIGA POE SWITCH
HF-SG08G2-96WGE
Product Features
- 8* 10/100/1000 Mbps Poe RJ45 ports (Port1 Port8)
- 2* 10/100/1000 Mbps Poe RJ45 ports (Port9~ Port10)
- Support upto 250m with CCTV Extension Mode
- Max Poe power : 7/8 th ports max60W; 1-6th ports max 30W
- Maximum power of Poe: 96W
- All Ports supports 6kv lightning protection
Specifications
- Specifications:
Specifications:
Networking Ports
8* 10/100/1000 Mbps Poe RJ45 ports (Port1~ Port8) 2* 10/100/1000 Mbps Poe RJ45 ports (Port9~Port10)
Network Standard
IEEE 802.3i, IEEE 802.3u, IEEE 802.3x, IEEE 802.3af, IEEE 802.3at, IEEE 802.3bt
Performance
Bandwidth: 11.2 Gbps Packets Forwarding Rate: 1.49Mpps MAC table size: 1K Forwarding type: Storage and Forwarding
LED
Power Indicator LINK/ACT Indicator PoE Indicator
POE
1/2(+), 3/6(-)
POWER
Port 7-8 max power: 60W PoE budget: 96 W
Dimension
WxDxH: 210mmx152mmx40mm
Evironment
Working Temperature: 0°~ 40 °C Storage Temperature: -40°C~70°С हर CEFC Working Humidity: 10% ~ 90% RH nun-condensing Storage Humidity: 5%~ 90% RH nun- condensing
