Innovation

Precision at Any Hour: Industrial-Grade Thermal Camera for Border Surveillance and More

In today’s world of 24/7 security demands, the Hi-focus Thermal Camera (HC-IPC-SD464TH ) offers unmatched visibility — even in total darkness, fog, or smoke. Powered by a 12μm VOx thermal sensor and a 50mm lens, this advanced dual-spectrum camera is tailor-made for applications demanding long-range heat detectionAI-based tracking, and fire or intrusion detection in the harshest conditions.

 Key Features of the HC-IPC-SD464TH Thermal Camera

  •  Dual-Spectrum Imaging: Merges thermal and visible light feeds

  •  50mm VOx Thermal Sensor: Delivers up to 0.24mrad spatial resolution

  •  Accurate Temperature Measurement: Range -20°C to +550°C, ±2°C accuracy

  •  Smart Alarms: AI-based fire alerts, intrusion detection, temperature thresholds

  •  360° Pan + 90° Tilt: High-speed PTZ with ±0.05° precision

  •  IP66 Certified: All-metal body with self-inductive wipers for outdoor use

Lens Options and Use-Case Adaptability

The camera features multiple lens configurations — 9.1mm, 13mm, 25mm, and 50mm — making it adaptable for both wide-area monitoring and long-distance thermal targeting.

LensFOV (H×V)Spatial Resolution Ideal Application

9.1mm 48°×38° 1.32 mrad Indoor safety, warehouse monitoring

25mm 17°×14° 0.48 mrad Perimeter protection, small campuses

50mm 8.8°×7.0° 0.24 mrad Border surveillance, forest fire detection

Industrial Applications of Thermal Cameras

1. Border Surveillance and Military Perimeter Security

  • Detects intruders or vehicles at long distances with 50mm lens

  • Operates in total darkness or during harsh weather

  • Triggers PTZ tracking and visual alerts automatically

2. Oil & Gas Facilities

  • Identifies overheating pipelines or leaks

  • Reduces explosion risks with real-time fire detection

  • Supports remote monitoring via ONVIF, SDK, GB28181

3. Forest Fire Detection

  • Continuously scans large forested zones with high-accuracy thermal vision

  • Detects ignition points early and sends linked alarms to command centers

  • Operates in -40°C to +70°C, ideal for rugged terrains

4. Critical Infrastructure (Dams, Power Plants)

  • Detects temperature anomalies in generators or transformers

  • Monitors restricted zones with cross-border intrusion analytics

  • Ensures operator safety through non-contact diagnostics

5. Airport & Port Surveillance

  • Monitors tarmac or harbor areas for unusual temperature fluctuations

  • Enhances night-time perimeter protection without extra lighting

  • Integrates with NVRs and VMS systems for centralized control

 Smart Thermal Features That Set It Apart

  •  Human/Vehicle Detection: AI-powered filtering reduces false positives

  •  Intelligent Scene Configuration: Multi-scan modes for varied terrain

  •  Fire Detection Algorithms: Auto-identifies abnormal temperature spikes

  •  Temperature Analysis Tools: Line/Point/Area for precise reporting

  •  Two-Way Audio & Talkback: Ideal for remote warnings or communication

Rugged and Ready for the Outdoors

Built to perform in extreme environments, this camera is IP66-rated with a self-cleaning wiper, ensuring clear thermal imaging in rain, dust, or sandstorms. Its metal housing, support for 24V AC/DC, and maximum 48W power usage make it fit for long-term deployment in remote or high-risk zones.

Final Thoughts: The Ultimate Thermal Camera for Defense, Industry & Safety

The Hi-focus Thermal Camera isn’t just a camera — it’s a mission-critical surveillance system. Whether you’re securing a national border, protecting critical infrastructure, or enhancing wildfire detection, this device delivers the precision, durability, and intelligence needed to protect what matters most.
